| Section |
Width (w) (mm) |
Height (h) (mm) |
Thickness | Weight | Section Modulus |
Moment of Inertia Wall (cm⁴/m) |
Coating Area |
|
|---|---|---|---|---|---|---|---|---|
|
(t) (mm) |
Pile (kg/m) |
Wall (kg/m²) |
Elastic Wall (cm³/m) |
Both (m²/m) |
||||
| OSW 9.5 | 500 | 45 | 10 | 64 | 128 | 46 | 168 | 1.054 |
| OSW 11 | 500 | 45 | 11 | 71 | 141 | 49 | 186 | 1.054 |
| OSW 12 | 500 | 47 | 12 | 74 | 149 | 51 | 196 | 1.054 |
| OSW 12.5 | 500 | 47 | 13 | 76 | 153 | 51 | 201 | 1.054 |
| OSW 12.7 | 500 | 47 | 13 | 77 | 154 | 51 | 204 | 1.054 |
